Tile Cassette & Magnet Quick-Swap Guide
1
Remove slide plates using the correct driver for your Tile.
Note: Depending on Tile model, screws may be Phillips PH 1.5, Hex 1.5 mm, or Torx T6).
2
Using a stack of spare disc magnets, touch them to any magnet inside the cassette and pull one free.
Note: Some magnets pull easier than others and may take a few pulls before removal.
3
Slide a flat-head into the empty pocket and gently pry the cassette out.
4
Press the new cassette in until it is nested completely inside the Tile body.
5
Load magnets on one half of your Tile – keep all eight in the same polarity (a metal tray underneath helps).
6
Flip the magnet stack to reverse polarity and load the other half of your Tile.
7
Re-install the two slide plates with the same driver used in Step 1.
